N3081/N3083N SERIES ANALOG INPUT MODULE Specifications Advantages Models Installation N-Series Family N Series Distributed I/O Measure. Convert.Monitor. N3081/N3083 provide 8 single-ended analog input channels. Select N3081 for 0–20 mA / 4–20 mA current signals or N3083 for 0–5 V / 0–10 V voltage signals. Each model delivers 16-bit resolution, ±0.1% FSR accuracy at 25°C, and a 300 ms sampling period.
Key specifications
N3081
N3083
Current input
Voltage input
0–20 mA / 4–20 mA
0–5 V / 0–10 V
Single-ended, 4-wire
Single-ended, 4-wire
16 Bit
16 Bit
300 ms
300 ms
Supply information
Manufacturer
BLIIoT — Beilai Technology Co., Ltd.
Model code
N3081/N3083
Full name
N3081 / N3083 8-Channel Analog Input Module
Category
N-series I/O boards
Supplied in Korea by
ACUSYS Co., Ltd. · Official BLIIoT distributor in Korea
